GP4224-08013

Product Categories
Product Families
Category: Tags: ,
Total Number of Ports:

24

Dimensions:

41.5” (1053.5 mm) H x 39.5” (1004.0 mm) W x 7.4” (188.5 mm) D

Download Datasheet

More Information

Contact customer support.

GP4224-08013

Dual-Band 6/6 Multibeam 2×2 Antenna [1695-2690/3300-4000 MHz]

Description:

  • 2×2 MIMO 6/6 beam antenna for high-capacity stadium/venue or special events applications
  • 6-beams (12-ports) 1695-2690 MHz; each beam with 2×2 MIMO capability
  • 6-beams (12-ports) 3300-4000 MHz; each beam with 2×2 MIMO capability
  • 6° Fixed Electrical Downtilt in all bands
  • Patent pending technology allows for stable azimuth beam directions over the entire operating frequency band
  • Excellent alternative to large lens-based multibeam antennas
  • External ruggedized features of the antenna enclosure provide added protection during the installation process
  • Optional heavy-duty transport case is provided to prevent damage for multiple deployment scenarios
Total Number of Ports

24
Height

41.5"
With Mounting Kit

Yes
Color

Gray
Connector

4.3-10
Diversity

2×2
Mid Band 1 Frequency Range

1695-2690MHz
Mid Band 1 Number of Ports

12 (6xBeam, 2×2 MIMO)
High Band 1 Frequency Range

3300-4000MHz
High Band 1 Number of Ports

12 (6-Beam 2×2 MIMO)
Connector Option 1

4.3/10-F
Request a Quote
