GP3324-07769

Product Categories
Product Families
SKU: N/A Category:
Total Number of Ports:

24

Dimensions:

32.7” (831.8 mm) x 20.1” (511.0 mm) x 7.0” (177.0 mm)

Download Datasheet

More Information

Contact customer support.

GP3324-07769

C-Band 6-Beam 4×4 Antenna [3300-4000 MHz]

  • 4×4 MIMO 6-beam antenna for high-capacity stadium/venue or special events applications
  • 6-beams (24-ports) 3300-4000 MHz; each beam with 4×4 MIMO capability
  • 6° Fixed Electrical Downtilt
  • Patent pending technology allows for stable azimuth beam directions over the entire operating frequency band
  • Excellent alternative to large lens-based multibeam antennas
Height

32.7"
Total Number of Ports

24
With Mounting Kit

Yes
Color

Gray
Connector

4.3-10
Request a Quote
